Data Panel - xtremeDB passive module XDB-6-SIM DP-34045-6-000

Product may differ from image

Data Panel - xtremeDB passive module XDB-6-SIM

10x DT4P - 16 signal, sensor power

Art.No.:	DP-34045-6-000
Weight:	0.68 kg
Country of origin:	US

Out of Stock - Contact Us for Availability

Find similar Product

Ask question

Recommend Product

Product Comparison

Description

10-way, 4-pole, 16 signals
without LED
Plug connection DT-4P
IP69K (when using MDC xtreme connection cables)
Connection cables are in the online shop under "Connection Technology".

Technical Data

Contact Layout

PIN 1	(+)
PIN 2	(NC)/(S2)
PIN 3	(-)
PIN 4	(NO)/(S1)
PIN 5	(Earth)

Product article number of manufacturer	DP-34045-6-000

Commercial data

ECLASS-6.1	27279219
ECLASS-7.0	27279219
ECLASS-8.0	27279219
ECLASS-9.0	27440111
ECLASS-10.1	27440111
ECLASS-11.1	27440111
ECLASS-12.0	27440111
customs tariff number	85369010
EAN	89336773352
Packaging unit	1

Downloads

Data Regarding Article:

Download Data Sheet
Download Construction files: DXF DP-34044-1-200_dxf_x_a.zip
Download Construction files: P8 DP-34045-6-000_p8_2_50.zip
Download Construction files: STP DP-34044-1-200_stp_x_a.zip
Download Document: Installation guide DP-34045-6-000_ina_10_04.pdf
Download Document: Product data DP-34045-6-000_pd_2_10.zip
Download Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
Download Information: Certificate of conformity Murrelektronik GmbH 10-11-20_(1) RoHS REACh exception 6c_DoC_z_a.pdf
Download Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf
Download Information: EU declaration of conformity DP-34045-6-000_EU-Cert-2_ce_z_a.pdf
