MCS POWER SUPPLY 3-PHASE,

IN: 360-550VAC OUT: 24-28V/40ADC
Art.No.: 85099
Alternative product:    85004
Weight: 4.5 kg
Country of origin:  CZ
Out of Stock - Contact Us for Availability
 Product Comparison
List price per piece:
Download to Easy-Import-Export

Description

INPUT: 3× 360...550 V AC
OUTPUT: 24...28 V DC
Current: 40 A
Certificate
Certificate
Certificate
Certificate
Certificate
Certificate

Input
Input voltage 3× 360...550 V AC
Primary fusing external max. 3× 4 A
Input current 3× 1.7 A
Inrush current after 1 ms max. 4 A
Frequency 50...60 Hz
Output
Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
LED display LED (green) for output voltage
Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
Output current 40 A (+60 °C); 46 A (+40 °C)
Mains failure bridging time max. 8 ms (440 V AC)
Ripple max. 20 mV eff/rms
Spikes max. 150 mV ss/pp
Unit protection short-circuit and overload protected
Parallel usage/serial usage max. 5 units/max. 2 units
General data
Standards IEC 61010-2-201, EN 61204-3, EN 55022 B
Mounting method Screw fixing M4, 4 pcs. in rectangle 81×230 mm
Temperature range 0...+60 °C (storage temperature -25...+85 °C)
Relative humidity 5...95%, no condensation
Efficiency 91%
Dimensions H×W×D 242×106×270 mm

ECLASS-6.0 27049002
ECLASS-6.1 27049002
ECLASS-7.0 27049002
ECLASS-8.0 27049002
ECLASS-9.0 27040701
ECLASS-10.1 27040701
ECLASS-11.1 27040701
ECLASS-12.0 27040701
ETIM-5.0 EC002540
customs tariff number 85044083
EAN 4048879080460
Packaging unit 1


Data Regarding Article:
  • Download Product-PDF
  • Download Approval: CSA CA 85099_080128-0-000-C3211-07_csa_z_a.pdf
  • Download Approval: CSA US 85099_080128-0-000-C3211-87_csau_z_a.pdf
  • Download Approval: EAC 85099_ЕАЭС RU С-DE.АБ53.В.03597-2027.02.14_eac_z_b.pdf
  • Download Approval: UL Listed CA 85099_E196712_NKCR7_ulc_z_b.pdf
  • Download Approval: UL Listed US 85099_E196712-NKCR_ul_z_c.pdf
  • Download Approval: UL Registered CA 85099_E213413-QQGQ8_urc_z_c.pdf
  • Download Approval: UL Registered US 85099_E213413-QQGQ2_ur_z_c.pdf
  • Download Construction files: DXF 85099_dxf_x_a.zip
  • Download Construction files: STP 85099_stp_x_a.zip
  • Download Document: Installation guide 85099_ina_4_16.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 05-02-23_(2) China RoHS 2 20EEP_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 13-11-20_(2) RoHS REACh exception 7cI_DoC_z_c.pdf
  • Download Information: Certificate of conformity UKCA 85099_46-10.20_uk_z_a.pdf
  • Download Information: EU declaration of conformity 85099_46-10.20_ce_z_c.pdf
  • Download Information: MTBF Report 85099_SN29500(40°C)-BerechnungV1.4_mtbf_p_a.pdf
